ARRI LDS Ultra Prime 16
LDS Ultra Prime 16 offers floating elements for outstanding close-up performance, covers Super 35 and genuine internal focus for sensitive focusing.
The Arri / Zeiss LDS ultra prime 16 weight 1.5 Kg with a front diameter of 104 mm / 4.1" and close focus at 0.25 m / 9.8". The ARRI LDS Ultra Prime lenses consists of Ultra Prime optical elements transplanted into specially designed housings that allow each lens to communicate with the camera electronically, easing tasks on set and providing valuable metadata for postproduction.
Key Features:
- Floating elements for outstanding close-up performance
- covers Super 35
- Genuine internal focus for sensitive focusing
- Increased image contrast and resolution over the entire focal range
- Super color matched with Ultra Prime, Master Prime, and Alura ZoomsUniform and constant position of scales
- Built-in encoders and electronic PL mount (PL-LDS) for lens metadata
- Positive locking (PL) 54 mm stainless steel lens mount with Lens Data System (LDS) contacts
- Close focus is measured from the film/sensor plane
- Magnification ratio is the relationship of the size of an object on the film/sensor plane (first number) to the size of that object in real life (second number) at the close focus setting
- Lens length is measured from the lens mount to the front of the lens housing
- Diameter of the lens/matte box interface
| WEIGHT | 1.5 Kg / 3.3 lb |
|---|---|
| LENGTH | 94 mm / 3.7" |
| APERTURE | T1.9 to T22 |
| LENS FIT & MOUNT | PL LDS |
| FRONT DIAMETER | 104 mm / 4.1" |
