audio-technica MCB4

MCB4 ANTENNA COMBINER

Broadband UHF operation (440-865 MHz range)
Combines the signals of up to four wireless in-ear monitor transmitters
Centralised power supply with ability to power four individual transmitters
Maintains clean signals with low distortion

MCB4

MCB4

MCB4 ANTENNA COMBINER

Audio-Technica MCB4 Antenna Combiner allows the signals of up to four M3 Wireless In-Ear Monitor stereo transmitters to be combined onto a single transmitting antenna, reducing rack clutter.

A wide-band unit that operates over the 440-865 MHz range, the MCB4 is designed to complement Audio-Technica M3 Wireless In-Ear Monitor Systems. It is also suitable for many other in-ear wireless systems (with external BNC antenna connections) operating within the 440 to 865 MHz range. The MCB4 provides one output and four isolated transmitter inputs. All RF connectors are BNC-type.

Four jacks on the rear panel (controlled by the unit's power switch) provide 12V DC (centre positive) to power as many as four transmitters operating on 12 volts at up to 600 mA each. Included with the unit are four DC cables appropriate for use with M3T (or like-powered) transmitters. The 12-volt supplies for powering transmitters are short-circuit protected. The unit features all-metal construction for extreme durability and protection from radio frequency interference.
  • Broadband UHF operation (440-865 MHz range)
  • Combines the signals of up to four wireless in-ear monitor transmitters into one antenna
  • Centralised power supply with ability to power four individual transmitters
  • Maintains clean signals with low distortion
  • Includes hardware for front-mounting the antenna for improved performance
  • Includes adaptors to allow the unit to be mounted into a single rack space
MCB4
Antenna & Distribution
Connections BNC Female (5 total)
Power Supply Desktop switching power supply rated at 5A @ 12V DC or 60 Watts. Input Voltage 100-240V AC via detachable IEC 320/ C14 cable. Output is provided on an over- molded 3-pin Molex-style termination
Dimensions 210.0 mm (8.27") W x 46 mm (1.80") H x 176.0 mm (6.93") D (one rack space)
Weight 1.0 kg (2.2 lbs.)
Accessories IEC 320/C14 power cable (for power supply); 5 – 22" RF (BNC to BNC) cables;
4-DC power cables; Rack kit for front- mounting antennas and adaptation to a 19" rack
Infrared
Bandwidth 440 – 865 MHz
