Sony PXW-FX9 XDCAM 6K Full-Frame Camera System (Body Only)
| Image Sensor Size | 35.7 x 18.8 mm (Full-Frame) |
| Sensor Type | CMOS |
| Sensor Resolution | Effective: 3840 x 2160 |
| ISO | 800 to 4000 (Native) |
| Gain | -3 to 18 dB |
| Advertised Dynamic Range | 15 Stops |
| Signal-to-Noise Ratio | 57 dB |
| Lens Mount | Sony E-Mount |
| Shutter Speed | 1/1 to 1/8000 sec |
| Built-In ND Filter | 4 to 128 Stop Electronic ND Filter |
| Built-In Microphone Type | Mono |
| Recording Media | 2 x XQD Card Slots 1 x SDXC/Memory Stick PRO Duo Hybrid Card Slot |
| Recording Modes | XAVC-I 4:2:2 10-Bit: 3840 x 2160p at 23.98/25/29.97/50/59.94 fps (240 to 600 Mb/s) 1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps (89 to 222 Mb/s) 1920 x 1080i at 50/59.94 fps (112 Mb/s) XAVC-L 4:2:2 10-Bit: 3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 150 Mb/s) 1920 x 1080p at 25/29.97/50/59.94/100/120 fps (25 to 50 Mb/s) 1920 x 1080i at 50/59.94 fps (50 Mb/s) MPEG HD422 4:2:2 10-Bit: 1920 x 1080p at 23.98/25/29.97 fps (50 Mb/s) 1920 x 1080i at 25/50/59.94 fps (50 Mb/s) XAVC Proxy 4:2:0 10-Bit: 1920 x 1080p (9 Mb/s) 1280 x 720p (6 to 9 Mb/s) 640 x 360p (3 Mb/s) |
| Gamma Curve | Sony S-Log 3 |
| Audio Recording | XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio Proxy: 2-Channel AAC Audio |
| Video Connectors | 1 x BNC (12G-SDI) Output 1 x BNC (3G-SDI) Output 1 x HDMI (HDMI 2.0) Output |
| Audio Connectors | 2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm Stereo Headphone Output |
| Other I/O | 1 x BNC Genlock Data Input 1 x BNC Timecode Data Input/Output 1 x 2.5 mm LANC Control 1 x USB Micro-B USB 3.1 Gen 1 Data |
| Wireless Interfaces | 2.4 GHz, 5 GHz Wi-Fi |
| EVF | Included |
| EVF Display Type | LCD |
| Screen Size | 3.5" |
| EVF Resolution | 2,760,000 Dots |
| Battery Type | Sony BP-U Series |
| Power Connectors | 1 x Barrel (19.5 VDC) Input |
| Power Consumption | 35.2 W |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Accessory Mount | 1 x Multi-Interface Shoe 1 x 1/4"-20 Female |
| Dimensions | 5.75 x 5.61 x 9.02" / 146 x 142.5 x 229 mm (Without Protrusions) |
| Weight | 4.4 lb / 2 kg |
| Package Weight | 18 lb |
| Box Dimensions (LxWxH) | 60 x 20 x 13" |
Full-frame creativity
Realize beautiful 4K imagery with the creative freedom made possible by oversampling a huge high resolution full-frame sensor. Capture every detail from the scene with shallow depth of field and stunning bokeh for a truly cinematic look. 15+ stops of dynamic range and Dual Base ISO enable you to capture every nuance, from subtle shadow detail to specular highlights, with an immaculate color palette.
Capturing the impossible
Make sure your story’s always clear with enhanced Fast Hybrid AF that tracks your subject with unprecedented speed, smoothness and precision. Its impact is transformative for premium documentary, commercial and event applications.
Shoot in comfort, expand your horizons
The FX9 revolutionizes full-frame cinematography with peerless ergonomics and advanced technology for on-the-go shooting. The world’s first full-frame electronic variable ND filter* transforms possibilities for shooting in variable lighting conditions. Built-in Wi-Fi and 12G-SDI support advanced workflows while the optional XDCA-FX9 extension unit further expands the operational possibilities of the PXW-FX9.
6K Full-Frame "Exmor R" sensor for stunning picture quality
The camera’s full-frame 6K sensor provides superb recording in DCI 4K* Ultra HD and HD resolutions. Powerful image processing with debayering and oversampling ensures image quality beyond the limits of conventional Super 35 mm sensors. The back-illuminated CMOS image sensor also uses Sony’s Exmor R technology for improved sensitivity and noise reduction. Compared to a 4K Super 35 mm sensor, the FX9’s 6K sensor has over twice the surface area while providing a wider angle of view and shallower depth of field.
